VISIOMODVisioMod Verto — Vertical Aluminium Slat Fence
Formerly known as Verto Vertical Slat Fence
Vertical aluminium slat fence — Lineo's twin rotated 90°. Same 30 / 50 / 80 / 140 mm slat profiles, same 20 mm depth, same RAL and woodgrain palette — but the rhythm runs vertically. Reads as a contemporary picket without the timber, ideal where the eye should travel up rather than along.
CARATTERISTICHE
4 vertical slat widths: 30 / 50 / 80 / 140 mm
Same RAL + woodgrain palette as Lineo
Identical view both sides — no visible fasteners
Heights 900 / 1200 / 1500 / 1800 / 2000 mm
Concealed top + bottom rails
SPECIFICATIONS
Slat width30 / 50 / 80 / 140 mm
Slat thickness20 mm hollow extrusion
Slat orientationVertical (perpendicular to grade)
Frame profile40 × 40 mm aluminium 6063-T5 — top + bottom rail
Standard heights900 / 1200 / 1500 / 1800 / 2000 mm
Maximum span2500 mm between posts
Posts60×60 / 90×90 mm aluminium — bolt-down or concrete-set
Surface finishQualicoat Class 2 powder coat — any RAL
Wind resistance (standard)1.0 kN/m² — Zone 1–2 inland
Wind resistance (coastal)1.4 kN/m² — Zone 3–4 coastal upgrade
Reference standardWind action design per EN 1991-1-4 + National Annex
